ZF-TT200
Specification:
| Model | ZF-TT200 |
| Machine size L*W*H(mm) | 11050*2237*2100 |
| Packing speed | 100-120P/min |
| Product size range H*Ф(mm) | H (12-80)*Ф(85-150) |
| Power supply | 3P/380V/50HZ/13KW |
| Net weight | 1500KG |
Introduction
ZF-TT200 is a high-speed sleeve labeling machine, which can reach 100-120 pieces per minute. This machine has 3 patented technologies and the host fully covered by 304# stainless steel. Mainly used for packing single roll OPP tape,cloth tape, crepe paper, double-sided tape, mesh tape, aluminum platinum tape, PVC electrical tape, etc. Side labeling machine can be connected to the back of TT200.
Features
1. Six axis cutter head, unique cyclotron cutting, cutting surface leveling.
2. Double positioning center guide post makes label guide delivery is more stable .
3. The newest patent design, with automatic feeding and automatic discharge card, the fastest speed can be up 100-120 packs per minute, greatly saving the labor cost.
4. The newest patent design, adding the device of holding film. It is not necessary to adjust the height of the tool when changing the different diameter of the tape. Only adjust the hand-wheel of the holding film and it is easy to operate quickly.
5. Separated control of the bottom set of label brush: a more precision for casting label.
6. Double electrical eye realizing, prevent wrong labeling or missing labeling. And system parameter will adjust by itself when the new speed adjusted and it is not need to adjust again, easy to operate.
7. The specially designed hot air circulation shrinkage furnace is good at shrinkage, energy saving, and can be used for a variety of packaging production line.
8. Function to realize the color and it can be used with the printed film.
