ZF-Z450X ZF-Z600X
Specification：
| Model | ZF-Z600X | ZF-Z450X |
| Machine size L*W*H(mm) | 5350*960*1370 | 4075*960*1400 |
| Product size range W*Ф(mm) | W(5-72)*Ф(80-220) | W(5-60)*Ф(40-150) |
| Packing speed | 50-100P/min | 50-100P/min |
| Power supply | 1P/220V/60HZ/5.4KW | 1P/220V/60HZ/4.4KW |
| Net weight | 500KG | 500KG |
Introduction
Pillow Type Packaging Machine mainly used for single-roll packaging of OPP tape, double-sided tape, foam adhesive, stationery tape, etc. Products can be packaged with printed film, and the packaging speed can reach 50-150 packages per minute, and the unpacked products will be automatically filtered. If your product needs to be single-roll packaged, then this machine is your best choice. This Pillow Type Packaging Machine is very suitable for small to medium-sized businesses that need to perform single roll packaging, especially those that produce multiple types of tapes or related office supplies. It not only improves work efficiency, but also ensures the quality of the final product, and is an ideal choice for realizing automated production processes.
Features
1. With servo control (three servos), bag length can be set and cut in one step, saving time and film.
2. Control by imported PCL and touched screen, setting the parameter data much easier。
3. It can store 100 kinds of packing parameters. Self failure diagnosis, clear failure displaying.
4. It can be packed by printed film. High sensitivity photocell, digital input of cutting and sealing position for extra accuracy.
5. Positioning stop function, not adhesive to cutters and no waste of packing film.
6. Simple driving system, more reliable and more convenient maintenance.
7. The sealing blade wont work and let the tape slip if the distance is wrong between two tapes. It will keep inversion station once the blade touching the tape, it is convenient to directly operate after reboot.
8. Without packing film, it will stop working automatically. It will save time and film material to improve the operation efficiency.
Adhesive Manufacturing: For packaging rolls of adhesive tapes and foams.
Stationery Production: For packaging stationery tapes and other office supplies.
Retail Packaging: For creating retail-ready packages that attract consumers.
If your business requires single-roll packaging for adhesive products, the Pillow Type Packaging Machine is the ultimate solution. Its combination of speed, precision, and versatility ensures that your products are packaged efficiently and professionally, ready for the market.
As a Pillow Packing Machine Manufacturers. If you have any questions about the product, please contact us!
