ZF-6352+ZF-S550
Specification:
| Model | ZF-P1600 | ZF-U450-XG |
| Machine size L*W*H(mm) | 1773*1725*1145 | 2010*774*1185 |
| Power supply | 1P/220V/50HZ/0.2KW | 1P/220V/50HZ/0.3KW |
| Net weight | 290KG | 260KG |
Introduction
This packaging production line is mainly used for flat packaging of OPP sealing tape, which can be combined packaging of 6, 4, 3, and 2 rolls and single packaging. It can also be used for packaging cloth tape, aluminum clamp tape, mesh tape, etc.
| Model | ZF-6352 |
| Machine size L*W*H(mm) | 1950*1570*1310 |
| Sealing blade size L*W(mm) | 630*515 |
| Product size range L*W*H(mm) | (80-560)*(60-430)*(5-250) |
| Power supply | 1P/220V/50HZ/3 KW |
| Net weight | 750KG |
| Model | ZF-S500 |
| Machine size L*W*H(mm) | 2000*1070*1230 |
| Product size range W*H(mm) | 400*300 |
| Power supply | 3P/380V/50HZ/12KW |
| Net weight | 550KG |
Features
1. The sealing machine is the latest patented design, vertical sealing design, four-post sealing structure, the knife holder is made of solid aluminum, and the sealing knife is an integral design; the sealing is stable and fast.
2. The fastest 6-roll flat packaging speed can reach 35 packs/min. The fastest single packaging speed can reach 40 bags/min.
3. The width can be easily adjusted, no tools are required, and the required size can be quickly changed.
4. The shrinking furnace is a high-efficiency and energy-saving type, with high wind power and low shrinking temperature, so that the product is evenly heated during the heat shrinking process and the shrinking effect is more perfect.
5. Discs and conveyor belts are all made of non-adhesive Teflon materials, which are never glued and durable.
6. It can be connected to the back of the automatic slitting machine and the manual slitting machine to realize automatic packaging in the back section.
