ZF-S450 S550 S650 S800
Introduction
Various types of heat shrinkable channels can be provided to meet the packaging requirements of different sizes of products. The temperature, wind power, wind direction and conveying speed of the heat oven can be adjusted, and the insulation layer design is adopted, which is energy-saving and environment-friendly. It can be connected with various types of zf-packaging machines to achieve full-automatic production line.
The high-efficiency and energy-saving heat shrink tunnel machine is suitable for a variety of industries, such as food and beverage, medicine, cosmetics, etc. It is an ideal choice for companies that need to package products with plastic film to achieve dustproof, waterproof, beautiful, etc. In addition, it can be seamlessly integrated with other packaging machinery to build a complete automated production line, greatly improving production efficiency and product quality.
Specification:
| Model | ZF-S450 | ZF-S550 | ZF-S650 | ZF-S800 |
| Machine size L*W*H (mm) | 1300*920*1130 | 2000*1070*1230 | 2200*1200*1230 | 2200*1250*1130 |
| Packing speed | 35m/min | 35m/min | 35m/min | 35m/min |
| Shrinkage size L*W*H (mm) | 1000*450*250 | 1500*540*350 | 1700*630*350 | 1700*700*280 |
| Power supply | 380V/50HZ/9.6KW | 380V/50HZ/9.6KW | 380V/50HZ/20KW | 380V/50HZ/23KW |
| Net weight | 350KG | 550KG | 630KG | 650KG |
Features
1. Downwind circulation fan system design, window design.
2. Three-layer board design, insulation thickness of 100mm, weight of the whole machine 550 kg, good insulation effect.
3. Wind and heat circulate in the furnace, which greatly saves heat energy and heats up quickly.
4. Wind power, direction and conveying speed can be adjusted, the shrinking effect is more perfect.
5. Simple operation, automatic temperature control, the temperature can be controlled within plus or minus 1 degree.
6. The whole machine is very energy-saving, 2-3KW/H energy-saving compared with other ordinary shrinking machines.
7. The main electrical heating pipes, fan motors are guaranteed for 10 years.
